Esko Kongsberg Bld-Tz512 Digital Finishing Tables V-Cut Knife Blades– Replacement

The Esko Kongsberg BLD-TZ512 (Part No. G42448597) is a specialized tungsten carbide knife blade designed for V-notch cutting on high-end digital finishing tables. Enquire now

Description

Esko Kongsberg BLD-TZ512 V-cut Knife Blades– Replacement

Description

Trapezoid shaped blade for straight cutting. This is a very good blade for cutting straight lines with the HD knife tool for PowerHead. Cuts materials up to about 17mm (0.67)

Recommended use

Very good blade for V-notch and straight cutting with the HD-knife tool in though materials such as Re-board, X-board and triple wall corrugated. Made from a special Tungsten Carbide alloy, to extend lifetime. Thickness 0,9mm ,035"

CUTTER BRAND
Esko Kongsberg
KNIFE HEIGHT
19,00 mm
THICKNESS
0,90 mm
MAX. CUTTING DEPTH
17,00 mm
KNIFE TYPE
Flat, V-cut
KNIFE/BLADE MOUNTING
flat 0,9 mm

Primary Applications

These blades are essential for industrial "V-cut" operations, typically involving:

Heavy Corrugated Cardboard: Creating clean folds for heavy-duty packaging.
Triple Wall Corrugated: Handling extremely thick materials that standard blades cannot fold.
Foam & Sandwich Boards: Angled cutting for structural displays and foam-core signage.
