SUMMA 500-9832 500-0832 F Series - POT Pneumatic Oscillating Cutter Tool Knives Blades

Summa 500-9832 (500-0832) is a heavy-duty, flat-point tungsten carbide knife blade designed specifically for the Pneumatic Oscillating Tool (POT) on Summa F Series flatbed cutters Enquire now

Description

SUMMA 500-9832 500-0832 F Series - POT Pneumatic Oscillating Cutter Tool Knives Blades

SUMMA 500-9832,SUMMA 500-0832,SUMMA POT Knife,SUMMA POT blades,SUMMA Point Knife,SUMMA Point blades,SUMMA Flat Knife,SUMMA Flat blades,SUMMA blade

Summa 500-9832 (factory designation 500-0832) is a heavy-duty, flat-point tungsten carbide knife blade designed specifically for the Pneumatic Oscillating Tool (POT) on Summa F Series flatbed cutters. Unlike standard oscillating blades that measure only 0.63 mm thick, this specialized blade features a reinforced 1.5 mm thickness. This extra mass prevents the blade from bending, twisting, or deflecting when power-cutting through highly rigid, tough, or structural materials.

Core Blade Technical Specifications

According to documentation from Summa Support, the specific dimensions for this heavy-duty profile include:

Blade Profile: Flat Point, single-edge heavy-duty oscillating blade.
Cutting Length (L): 20 mm.
Blade Thickness (T): 1.50 mm (replaces standard thin 0.63 mm blades for high-deflection jobs).
Shank Style: Ø 6 mm round Weldon shank.
Cutting Angle: Dual angle 12° / 82°.

Operational Parameters & Target Materials

Maximum Cutting Depth: Designed to process rigid materials up to 18 mm (0.71") thick.
Target Materials: Best suited for Twinwall plastic, corrugated plastics (Akylux/Coroplast), solid polycarbonates, dense foam boards, magnetic sheets, and thick 3M VHB structural tapes.
Recommended Cutting Speed: Optimized for 150 mm/sec. The added thickness provides structural stability, allowing faster forward tracking through tough plastics without breaking the blade tip.

OYEA Knives manufactures and supplies a full line of both STANDARD and CUSTOM leather cutting knives and blades. All of our standard leather cutting knives are manufactured to exceed the exact OEM standards.
