Aristo 000007728 Blade,Aristo Blades,Aristo 7659,Aristo 000007659,Aristo 0000 07659,ARISTO Cutter Blade

Product Categories

ARISTO 7728,000007728,0000 07728 Cutter Round Shank shaft Knife Blades For Sale Service

The Aristo 7728 (also listed as 000007728 or 0000 07728) is a premium, heavy-duty tungsten carbide oscillating knife blade designed for specialized CNC digital flatbed cutters Enquire now

Description

ARISTO Cutter Round Shank shaft Knife Blade 7728,000007728,0000 07728

Aristo 000007728 Blade,Aristo Blade,Aristo 7659,Aristo 000007659,Aristo 0000

Key Technical Specifications

Shank Diameter: 8.0 mm (Thicker shaft designed for highly demanding or thick materials) (Note: Some aftermarket manufacturers can supply a modified 6mm version upon custom corporate request)
Maximum Cutting Depth: 38.0 mm to 39.0 mm (approx. 1.5 inches)
Total Knife Length: 49.5 mm
Cutting Angle: 84.5°
Blade Tip Geometry: Centrical tip
Material Composition: Solid Virgin Tungsten Carbide / Tungsten Steel

Recommended Material Processing

Due to its robust 8mm profile and extended length, it withstands substantial lateral force, making it ideal for deep oscillation cuts through:

Tough Industrial Fibers: Aramid (Kevlar), composite fiberglass, and carbon fibers.
Dense Gasket Materials: Heavy industrial rubber, neoprene sheets, compressed non-asbestos gaskets, and magnetic foils.
Thick Packaging & Foams: Heavy structural honeycomb board, multi-wall corrugated cardboard, solid carton, thick foam board, and soft polyester foam blocks.

Machine & Tool Head Compatibility

Aristo Systems: Engineered to fit the factory Aristo MultiHead IV and MultiHead V specialized cutting configurations equipped with motorized stroke adjustment.
Tool Holders: Plugs natively into standard Ø 8.0 mm round shank knife sleeves.
Alternative Cross-References: Often used interchangeably on third-party digital cutting tables outfitted with heavy-duty 8mm oscillating chuck modules

OYEA Knives manufactures and supplies a full line of both STANDARD and CUSTOM leather cutting knives and blades. All of our standard leather cutting knives are manufactured to exceed the exact OEM standards.
