Elitron 135304 Oscillating Knife Blades For Elitron Cutting Systems & Cutting Intelligence

Elitron 135304 (8MCLMA135304) is a premium solid tungsten carbide oscillating knife blade engineered specifically for Elitron CAD/CAM digital flatbed cutting systems Enquire now

Description

Elitron 135304 Oscillating Knife Blades For Elitron Cutting Systems & Cutting Intelligence

Elitron Knife,Elitron 135304,Elitron 135304 Blade,Elitron Blade 135304,Elitron Blade,Elitron Blades

Elitron 135304 (often indexed under part number 8MCLMA135304) is a premium solid tungsten carbide oscillating knife blade engineered specifically for Elitron CAD/CAM digital flatbed cutting systems. Designed to work alongside Elitron's proprietary "Cutting Intelligence" software, this compact blade maximizes cutting precision and structural edge quality during high-frequency vibration cycles.

Key Technical Specifications

Blade Profile: Flat, single-edge oscillating blade.
Length / Height: 29.00 mm.
Width: 5.60 mm.
Blade Thickness: 0.60 mm.
Cutting Angle: 25° bevel angle.
Material Composition: 100% Micro-grain tungsten carbide, providing maximum thermal stability and wear resistance under continuous mechanical friction.

Core Material Applications

The thin 0.60 mm profile combined with a acute 25° cutting angle makes the 135304 exceptional for intricate geometry, sharp corner radii, and fine-detail nested cutting. It is primarily deployed to process:

Footwear & Leather Goods: Natural hide prototyping, automotive leather, synthetic eco-leather, and lining textiles.
Packaging Prototypes: Fine folding cartons, dense paperboards, and technical foils.
Gasket & Industrial Media: Thin technical rubbers, polymers, and non-woven fibrous materials.

Tool Head & Machine Compatibility

This blade is a direct-fit consumable for Elitron’s specialized high-frequency electrical and pneumatic oscillating tool heads. It is actively utilized across several of Elitron’s core automated production lines:

Elitron Kombo Series: Built for the high-speed material handling cycles of platforms like the Kombo SD, Kombo Spark, and Kombo TAV.
Elitron Booster & Dinamo Series: Seamlessly handles precise nested cuts on dedicated dynamic conveyor leather and textile plotting systems.

OYEA Knives manufactures and supplies a full line of both STANDARD and CUSTOM leather cutting knives and blades. All of our standard leather cutting knives are manufactured to exceed the exact OEM standards.
