Esko Kongsberg Bit-Mus06-3014-50 G42459537 Milling And Router Bits China

Esko Kongsberg BIT-MUS06-3014-50 (G42459537 or 42459537) is an industrial-grade, single-flute up-cut multi-purpose milling and router bit. It is specifically engineered for high-performance routing on digital flatbed precision cutting tables, such as the Kongsberg Precision Cutting Systems platforms… Enquire now

Description

Esko Kongsberg Milling & Router Bits BIT-MUS06-3014-50 G42459537

Esko Kongsberg Bit-Mus06-3014-50 G42459537 Milling And Router Bits

Technical Specifications

The official nomenclature breaks down the structural dimension properties of this solid tungsten carbide tool:

Shank Diameter: 6 mm
Cutting Diameter: 3 mm (indicated by the "30" in the part name)
Flute Length (Cut Depth): 14 mm (indicated by the "14" in the part name), ideal for routing materials up to ½ inch thick.
Overall Length: 50 mm
Geometry: Single-flute, up-cut spiral layout designed to extract debris upwards away from the substrate.

Operational Hardware Compatibility

This tool fits standard 6 mm collet architectures across major industrial plotting platforms. Within the Kongsberg ecosystem, it is designed for:

High-Power Milling Unit (HPMU)
MultiCUT-HP tool heads

Application & Material Yields

The up-cut spiral design rapidly clears out waste material during high-RPM operations, protecting both the tool edge and the workpiece from heat-induced melting or weld-back. This makes it highly versatile across several broad industries:

Metals: Aluminum sheets and Aluminum Composite Materials (ACM / Dibond).
Plastics: Acrylic, Polycarbonate, and Foamed PVC (Forex/Sintra).
Woods: Solid wood, Plywood, and Medium-Density Fibreboard (MDF).
