Multicam BT-57220 84-00193-BT-57220 003612-MC142022 K90 Round Shank shaft Knife Blades

CHINA XK3020-OFP Multicam BT-57220 84-00193-BT-57220 003612-MC142022 K90 Round Shank shaft Knife BladesMulticam BT-57220 (cross-referenced as 84-00193-BT-57220, 003612-MC142022, and K90) is a high-precision, solid tungsten carbide oscillating knife blade engineered for MultiCam CNC digital cutting … Enquire now

Description

Multicam BT-57220 84-00193-BT-57220 003612-MC142022 K90 Round Shank shaft Knife Blades

Multicam BT-57220 (cross-referenced as 84-00193-BT-57220, 003612-MC142022, and K90) is a high-precision, solid tungsten carbide oscillating knife blade engineered for MultiCam CNC digital cutting systems.

Technical Specifications

Blade Type: Flat Point, Single Edge oscillating knife.
MultiCam Equivalent: K90 style.
Shank Diameter: 6.0 mm round shank.
Cut Length: 20 mm (typically used for materials up to 18 mm thick).
Overall Length: 39 mm.
Compatible Tool Holders: MultiCam OSCILLATE/KH6 tool heads.

Application and Performance

Target Materials: Best suited for processing soft foams, loose fabrics, corrugated cardboard, and soft plastics.
Cutting Profile: The flat tip design is optimized to shear loose fabrics and thick foams more effectively than pointed blades. However, it is less suited for highly intricate or tight-radius detailed cuts.
Material Composition: Manufactured from fine-grain tungsten carbide, which provides exceptional edge retention and helps prevent tool flexing under heavy vibration.

Equivalent to: Summa 500-9830, MultiCam 84-00193-BT-57220, AXYZ B1031l-20, MultiCam 003612-MC142022

OYEA Knives manufactures and supplies a full line of both STANDARD and CUSTOM leather cutting knives and blades. All of our standard leather cutting knives are manufactured to exceed the exact OEM standards.
