Multicam 84-00193-BT-562135 Carbide Round Shank Oscillating Knife Blades For Multicam Cnc Routers

MultiCam BT-562135 (84-00193) is an industrial solid tungsten carbide oscillating knife blade engineered for deep-reach cutting on MultiCam digital cutting tables and CNC router knife modules. Enquire now

Description

Multicam 84-00193-BT-562135 carbide round shank oscillating knife blades For Multicam Cnc Cutting Systems&Cnc Routers

MultiCam 84-00193-BT-562135 is a heavy-duty, solid tungsten carbide round-shank oscillating knife blade engineered for high-frequency vertical vibration cutting on MultiCam CNC automated digital cutting tables and routing machines

overall length
104.5mm
diameter
6.00mm
cutting length
88.5mm
cutting angle
90°
geometry
2 cutting

Key Technical Attributes

Premium Carbide Build: Formulated from ultra-fine grain solid tungsten carbide, delivering superior wear resistance and razor-sharp edge retention through continuous high-vibration passes.
6mm Round Shank: Features a standard cylindrical 6.00 mm shank diameter designed for precise concentricity and strict torque clamping within standard tool holders.
Extended Reach Deep Cutting: Features a long blade height profile specifically engineered to execute clean, straight 90-degree cuts through extra-thick composite sheets and thick structural panels without binding or blade deflection.

Primary Material Workloads

Thick Technical Foams: Ideal for structural packaging, cross-linked polyethylene (XLPE), and expanded polystyrene (EPS).
Heavy-Duty Core Boards: Honeycomb boards, thick structural foam-cores, and layered graphic displays.
Dense Composites: Advanced non-woven acoustics, thick insulating mats, and semi-rigid industrial gasketing
