Universal Cutting Tool (UCT) - For most cutting operations. Uses a variety of inserts. Does not oscillate, drags blade through material.
V-Cut Tool (VCT) - For cutting angles in soft material. As this tool drags the knife through the material, it is not suitable for very thin material as it lifts the material as it cuts, nor for very thick material, as the material begins to crush rather than cut. 1/8" - 3/18" foam core is a reasonable material range for this tool.
Electric Oscillating Tool (EOT) - For soft materials such as cardboard or foamcore. Good when UCT excessively drags or deforms the material.
Pneumatic Oscillating Tool (POT) - like EOT but with greater blade throw. Good with thicker materials that the EOT has trouble cutting cleanly. The POT cuts a little cleaner than the EOT, but because it is pneumatic and runs off the same compressor as the Onsrud and woodshop air hookups, it cannot be used while the others are running. Only use the POT if the Onsrud is not currently operating.
Driven Rotary Tool (DRT) - Uses a rotating circular blade. For fabrics and fabric like materials. Minimizes force acting on the material, but has the greatest overcut due to the blade geometry.
Router Module (RMA) - For routing or engraving materials that cannot be cut with a knife. Uses router bits whose diameter also limits depth of cut, potentially. Small parts may require bridges to maintain connection to surrounding material while being cut.
