Summa F Series - HF Router Maintenance and Adjustment of Spindle Collet
Maintenance of Summa F series high-frequency end mills includes weekly chuck cleaning, annual chuck replacement to ensure maximum clamping force, and precise air pressure control during tool changes. Key steps include: initiating compressed air via the axis control system to install the chuck, hand-tightening (maximum torque 0.5 Nm), and ensuring the retaining screws are secure to prevent rotation.
High-Frequency End Mill Spindle Chuck Installation (System 4041 DC-S)
1. Preparation: Initiate tool changer via the axis control system and turn on the switch on the end mill module to apply compressed air.
2. Install Chuck: Hand-screw the chuck along with the dummy tool into the spindle until it reaches the limit stop.
3. Tighten: Gently tighten the chuck (maximum torque 0.5 Nm) using the included tool.
4. Adjust Stroke: Loosen the chuck by 1/2 turn and ensure the retaining screws are tightened to prevent the chuck from loosening during operation.
5. Completion: Insert the tool, turn off the compressed air, and reset the machine to online mode. Maintenance and Best Practices
• Weekly Cleaning: Clean the chuck assembly weekly to remove residue. Clean the inside of the end mill spindle, the chuck nut, and the chuck itself to ensure consistent clamping force.
• Annual Replacement: Replace the chuck annually to maintain optimal clamping force.
• Chuck Protection: If the retaining screws are not tightened, the chuck may rotate and loosen, causing damage.
• Tool Use: Use dedicated tools for specific materials; to ensure edge quality, do not reuse tools on different types of materials.
• Tool Down Position Setting: When installing a new tool, adjust the tool down so that the tip just touches the guard pad. Using the wrong position may damage the tool.
Maximum Depth of Milling
• Limitation: The maximum depth of milling is 25 mm.
• Recommendation: The ideal maximum depth of milling is 1.2 times the end mill diameter.
• Safety: Always use the guard pad under the material. With the guard pad, the total clearance under the end mill module is 30 mm.
Summa Cutting Blades/Knives
High-Frequency End Mill Spindle Chuck Installation (System 4041 DC-S)
1. Preparation: Initiate tool changer via the axis control system and turn on the switch on the end mill module to apply compressed air.
2. Install Chuck: Hand-screw the chuck along with the dummy tool into the spindle until it reaches the limit stop.
3. Tighten: Gently tighten the chuck (maximum torque 0.5 Nm) using the included tool.
4. Adjust Stroke: Loosen the chuck by 1/2 turn and ensure the retaining screws are tightened to prevent the chuck from loosening during operation.
5. Completion: Insert the tool, turn off the compressed air, and reset the machine to online mode. Maintenance and Best Practices
• Weekly Cleaning: Clean the chuck assembly weekly to remove residue. Clean the inside of the end mill spindle, the chuck nut, and the chuck itself to ensure consistent clamping force.
• Annual Replacement: Replace the chuck annually to maintain optimal clamping force.
• Chuck Protection: If the retaining screws are not tightened, the chuck may rotate and loosen, causing damage.
• Tool Use: Use dedicated tools for specific materials; to ensure edge quality, do not reuse tools on different types of materials.
• Tool Down Position Setting: When installing a new tool, adjust the tool down so that the tip just touches the guard pad. Using the wrong position may damage the tool.
Maximum Depth of Milling
• Limitation: The maximum depth of milling is 25 mm.
• Recommendation: The ideal maximum depth of milling is 1.2 times the end mill diameter.
• Safety: Always use the guard pad under the material. With the guard pad, the total clearance under the end mill module is 30 mm.
Summa Cutting Blades/Knives
