Multicam 84-00193-BT-56270 K118 Oscillating Weldon knife Blades – Replacement

Multicam BT-56270 (B2031L-70) is a tungsten carbide, cylindrical oscillating knife blade primarily manufactured for AXYZ and MultiCam CNC systems (part number 84-00193-BT-56270). The K118 (or "K12-K118" in tooling catalogs) Enquire now

Description

Multicam 84-00193-BT-56270 Oscillating Weldon knife Blades – Replacement

MultiCam 84-00193-BT-56270 Vibrating Cutter Blade(It is also commonly referred to in the industry as BT-56270 or K118)This is a double-edged, flat/round-shank carbide vibrating insert specifically designed for MultiCam CNC cutting systems.It exhibits extremely high cutting efficiency when machining soft or medium-density composite materials through high-frequency up-and-down vibration

CUTTER BRAND
Multicam

ANGLE
2×30°

KNIFE HEIGHT
86,00 mm

MAX. CUTTING DEPTH
69,00 mm

MATERIALS
Aramid fibers, Canvas, Canvas, Carbon fibers, Cardboard, Cork, Corrugated cardboard, Covering, Expanded polystyrene, Felt, Foam board, Folding Carton, Gasket materials, Glass fibers, Honeycomb, Insulating mat, Magnetic foil, Masking film, Non-woven fabric, Packaging materials, Paper, Polyester fabric, PVC, PVC, Reflective foil, Rubber, Synthetic materials, Textiles

KNIFE TYPE
Oscillating blade, Weldon

REPLACEMENT
Yes

KNIFE/BLADE MOUNTING
round Ø 6 mm

OYEA Knives manufactures and supplies a full line of both STANDARD and CUSTOM leather cutting knives and blades. All of our standard leather cutting knives are manufactured to exceed the exact OEM standards.
