ZUND Z17C FibreCut-coated Tungsten Carbide Cutting Knife Blades-Production Sales

Zund Z17C is a premium, specialized variant of the standard Z17 flat-stock knife blade. It combines a high-density solid tungsten carbide (HM) substrate with a proprietary fibreCut coating—a high-performance, submicron Diamond-Like Carbon (DLC) layer. This specialized coating is explicitly Enquire now

Description

ZUND Z17C FibreCut-coated Tungsten Carbide Cutting Knife Blades-Production Sales

ZUND Z17C,ZUND Z17,ZUND Z17C Blade,ZUND coated Blade,ZUND FibreCut Blade,ZUND Blade

ZUND Z17C FibreCut-coated Tungsten Carbide Cutting Knife Blades are top-tier, precision-engineered tools designed for use in automated digital flatbed cutters. These blades boast a unique FibreCut protective coating on a high-quality solid tungsten carbide base, which greatly improves durability and resistance to wear.

Application recommendations:	Paper, Folding cardboard, Banner, PVC, vinyl, Magnetic foil, Reflector foil, Self-adhesive foil, Sealing material, Protective foam, Fibreboard wood, Glass fiber fabric, Carbon fiber fabric, Fabric synthetic fiber, Canvas
Blade thickness (mm):	0.63
Coating:	fiberCut
Length (mm):	25
Max cutting depth (mm):	12
Pre-cut:	0,47 x Tm
Product material:	carbide, fine grain
Shaft width (mm):	5.65
Suitable for cutter:	Bullmer, Colex, Esko / Kongsberg, Mécanuméric, Zund / Wild, iEcho
Tip / shape:	single edge, pointed
Type:	drag blade, oscillating

Replaces:
Zund Z17 coated
Kongsberg BLD-SF217 coated
Bullmer B17 coated
iEcho E17 coated
Mécanuméric 100610390 coated

Key Performance Advantages

FibreCut Coating: This high-performance vacuum-deposited overlay functions similarly to a super-hard film (like
Extended Service Life: Due to the protective coating, coated blades frequently see an increase in operating life compared to uncoated tungsten carbide equivalents.
Minimal Overcut: The steep 65° profile is specifically optimized to execute sharp corners and complex geometries with tight radiuses while keeping overcut to an absolute minimum.

Tooling & System Compatibility

The Z17C blade is natively configured to load into standard 0.63 mm

Electric Oscillating Tool (EOT / EOT-250): Ideal for clean, rapid stroke execution on thin, flexible media.
Pneumatic Oscillating Tool (POT): Recommended for continuous, long-run heavy production through high-density or stacked industrial layers.
Static / Drag Tool Holders: Can also be deployed via the Universal Cutting Tool (UCT) or Scoring Cutting Tool (SCT) with appropriate insert sleeves.
Machine Match: Natively compatible with Zund G3, S3, and L3 digital cutting systems.

The ZUND Z17C FibreCut-coated Tungsten Carbide Cutting Plotter Knife Blades offer a premium solution for precision cutting needs. Designed with advanced FibreCut coating technology, these tungsten carbide blades are optimized for durability and performance, ensuring high-quality results across various applications. Specialized in production, manufacturing, wholesale distribution, and sales, this product delivers a balance of exceptional quality and competitive pricing. With an emphasis on customer customization, OEM and ODM services are available to meet specific requirements. Proudly manufactured in China by Shenzhen Oyea Machinery Co., Ltd., these blades reflect excellence in engineering and reliability, catering to diverse industry demands worldwide.
