Esko Kongsberg Bld-Sr6223 Round Shank Knife Blades For Kongsberg Machine Manufacturer G42437293

CHINA Esko Kongsberg BLD-SR6223 is a 6 mm round-shank, tungsten-carbide oscillating knife blade used on Kongsberg cutting systems. It is listed for general-purpose cutting on materials such as corrugated board, cardboard, foam board, folding carton, and vinyls. Enquire now

Description

Esko Kongsberg Bld-Sr6223 Round Shank Knife Blade For Kongsberg Machine Manufacturer G42437293

Kongsberg Bld-Sr6223 Blade,Kongsberg Bld-Sr6223,Kongsberg Blade,Esko Bld-Sr6223 Blade,Esko Bld-Sr6223,,Esko Kongsberg Blades,Esko Kongsberg Blade,Esko Blade,,Esko Blades,Kongsberg Blades

Esko Kongsberg BLD-SR6223 is an industrial-grade tungsten carbide vibrating blade, crafted specifically for high-precision digital cutting systems with the core code G42437293. This single-edge round blade is extensively utilized in packaging, advertising signage, and cardboard die-cutting applications.

Recommended use

Long life tungsten carbide blade. Works well with most kind of corrugated board

CUTTER BRAND
Esko Kongsberg
ANGLE
66°
KNIFE HEIGHT
39,00 mm
MAX. CUTTING DEPTH
12,00 mm
KNIFE TYPE
Oscillating blade, Weldon
REPLACEMENT
Yes
KNIFE/BLADE MOUNTING
round Ø 6 mm

Compatible devices and blade assemblies

This blade requires a specially designed "SR6xxx" blade adapter and is widely compatible with the following Kongsberg hardware ecosystem:

Applicable machine series : Kongsberg XE, XL, XN, XP, C series and V series digital cutting tables.
Applicable cutting tools : High Frequency Oscillating Knife Tool , Standard VibraCut / HF VibraCut, and Long Stroke Knife Tool.

Detailed Material Cutting Guide

Although they are general-purpose cutting blades, in actual production, the structure of different materials imposes different limitations on the vibration frequency and thickness of the cutting head.

Corrugated board : Ideal for cutting microflute, single-layer corrugated (A/B/C/E/F corrugated) and double-layer composite corrugated board (EB/BC corrugated).
Honeycomb & Cardboard : Supports cutting honeycomb sandwich panels up to 5mm thick.
Flexible foam board : Supports polyurethane (PUR) flexible foam core boards up to 5mm thick.
Plastics & Vinyls : Suitable for polyvinyl chloride foam boards (Sintra/Forex), double-wall hollow boards (Corrugated Plastic), and high-toughness vinyl banners with a thickness of less than 5mm .
Special fabrics : Industrial carpet materials with a thickness of <10mm and rubber backing can be cut

OYEA Knives manufactures and supplies a full line of both STANDARD and CUSTOM leather cutting knives and blades. All of our standard leather cutting knives are manufactured to exceed the exact OEM standards.
