Esko Kongsberg Bit-Mus03-3006-38 G42443432 Multi-Purpose Router Bits

Esko Kongsberg BIT-MUS03-3006-38 (G42443432 / 42443432) is a professional-grade, solid tungsten carbide multi-purpose up-cut single-flute router bit. It is engineered specifically for CNC milling operations on Kongsberg PCS cutting tables equipped with high-speed MultiCut or standard routing tool he… Enquire now

Description

Esko Kongsberg Bit-Mus03-3006-38 G42443432 Multi-Purpose Up-Cut Single-Flute Router Bits

Esko Kongsberg Bit-Mus03-3006-38 G42443432 Multi-Purpose Router Bits

Technical Specifications

Cutting Diameter: 3.00 mm
Max Cutting Length: 6.00 mm
Total Length: 38 mm (3.8 cm)
Flute Type: Up-cut, single flute (right-hand helix)
Material Composition: Premium solid tungsten carbide

Material Compatibility

This multi-purpose bit is optimized to perform reliably across a diverse material spectrum:

Metals & Composites: Aluminium sheets and Aluminium Composite Materials (ACM / Dibond).
Plastics: Acrylic (PMMA), Polycarbonate (PC), PETG, Polypropylene (PP), and Expanded PVC.
Wood Products: MDF, plywood, and solid wood varieties.

Tool Head & Machine Compatibility

To operate this 3mm bit on an Esko Kongsberg digital cutting system, it must be paired with specific high-speed tooling units:

High Power Milling Unit (HPMU)
High Speed Milling Unit (HSMU)
MultiCUT / MultiCUT-HP tool heads

Equivalent Alternative Part Numbers

If sourcing direct factory replacements or third-party equivalents, the following references map to this specific bit layout:

Kongsberg : SKU 42443432
Replaces Zund R74 / 3910755)
