Iecho Bk, Tk, And Pk Series Knives/Knife Blades Specifications Dimensions

Iecho Bk, Tk, And Pk Series Knives/Knife Blades Specifications And Dimensions

The iEcho BK, TK, and PK series knives and knife blades are part of iEcho's digital cutting systems designed for various cutting needs, materials, and precision levels. Below is a summary of their specifications and dimensions based on available information:

BK Series Knives/Knife Blades

· The BK series includes models like BK, BK2, BK3, and BK4, which are high-speed digital cutting systems.

· These systems support modular tools such as EOT, POT, UCT, KCT, and router spindles.

· BK series blades can cut medium to thick materials like foam board, cardboard, acrylic, MDF, ABS, and more.

· The blades typically have a thickness of about 1.5mm with cutting depths ranging from 1.1mm to 4mm depending on the blade type (e.g., PTK1 to PTK8 blades).

· The BK series supports various cutting tools including universal cutting tools, creasing wheels, kiss-cut tools, and oscillating knives.

· The BK series is suitable for flexible materials and complex patterns with high-speed operation

TK Series Knives/Knife Blades

· The TK series, including models like TK3S and TK4S, combines modular cutting heads similar to the BK series.

· TK series tools can perform cutting, notching, punching, labeling, and creasing.

· They can handle materials such as fabric, textile, non-woven fabrics, carpet, paper, cardboard, and foam board.

· TK blades also have a thickness around 1.5mm with cutting depths of 1.1mm to 4mm.

· The TK series supports automatic bit changing and advanced cutting functions.

· It is designed for large-format materials and equipped with roll feeders for efficient processing

PK Series Knives/Knife Blades

· The PK series is an automatic intelligent cutting system with models like PK0604, PK0705, PK129, and PK1209 Pro Max.

· Cutting areas vary by model, for example, PK0604 offers 600mm x 400mm, PK0705 750mm x 530mm, and PK129 1200mm x 900mm.

· The PK series supports universal cutting tools, creasing wheels, kiss cut tools, oscillating knives, and drag knives.

· It can cut materials including car stickers, vinyl, art card, PP paper, foam board, reflective materials, cardboard, corrugated plastic, ABS board, and magnetic stickers.

· Cutting thickness ranges from less than 2mm for smaller PK models to up to 10mm for the PK1209 Pro Max.

· The PK1209 Pro Max features 5 cutting modules and software-controlled cutting depth.

· The PK series uses vacuum systems for media holding and has a maximum cutting speed of up to 1500mm/s in some models.

· Power consumption is around 4KW, and the system is suitable for office and small production environments due to its single-phase power supply compatibility

Summary Table of Key Specifications

Series	Typical Blade Thickness	Cutting Depth Range	Cutting Area Examples	Materials	Special Features
BK	~1.5mm	1.1mm to 4mm	Modular, varies by model	Foam board, cardboard, acrylic, MDF, ABS	High-speed, modular tools, automatic bit change
TK	~1.5mm	1.1mm to 4mm	Large format with roll feeders	Fabric, textile, paper, cardboard, foam board	Notching, punching, labeling, creasing
PK	~1.5mm (blade holders)	<2mm to 10mm (PK1209)	600x400mm to 1200x900mm	Vinyl, stickers, PP paper, foam, cardboard, ABS	Intelligent automatic cutting, vacuum system, multi-tool modules

This overview captures the main specifications and dimensions of the iEcho BK, TK, and PK series knives and blades used in their digital cutting machines For detailed part numbers and exact blade dimensions, the iEcho product catalogs and technical datasheets provide comprehensive listings.
