Here is a detailed comparison of the Z6, Z10, Z11, Z44, Z46, Z101, Z102, Z103, and Z83 blades based on their design, materials, cutting angles, depths, and typical applications:
Z6 Blade
· Specifically designed for EGO POWER+ 52” Z6 Zero Turn Riding Mower.
· Made of all steel, 18” length.
· Intended for weekly mowing with clean cuts promoting lawn health.
· Used with EGO POWER+ ZT5207L model mower.
· Focused on lawn cutting performance rather than industrial cutting
Z10 Blade
· Tungsten carbide material, known for extreme durability.
· Dimensions: Length 50 mm, width 8 mm, thickness 1.5 mm.
· Double-edged drag blade with a cutting angle of 50° and cutting edge bevel of 46°.
· Max cutting depth around 4.8 mm.
· Suitable for a wide range of materials including canvas, cardboard, foil, plastic, and fabric.
· Compatible with Zund Universal Cutting Tool (UCT) and Scoring Cutting Tool (SCT).
· Used in Zund PN Series, G3 Series, and Kongsberg XL/XN series cutters.
Z11 Blade
· Similar to Z10 but designed for Zund S3, G3 & L3 digital cutters.
· Uses UCT (Insert sleeve 40) and SCT tool heads.
· Also tungsten carbide, designed for precision cutting.
· Compatible with Zund cutting machines with blade holder type number 3960322
Z44 Blade
· Tungsten carbide flat-stock drag blade.
· Dimensions: Length 50 mm, width 8 mm, thickness 1.5 mm.
· Cutting angle of 60°.
· Maximum cutting depth of 14 mm.
· Double-sided blade for less tough materials.
· Suitable for cutting Aramid fibers, Carbon fibers, corrugated cardboard, felt, foam board, leather, and polyester fabric.
· Used with Zund Universal Cutting Tool (UCT) and Scoring Cutting Tool (SCT)
Z46 Blade
· Tungsten carbide flat-stock drag blade.
· Dimensions: Length 50 mm, width 7.8 mm, thickness 1.5 mm.
· Cutting angle of 45°.
· Maximum cutting depth of 20 mm.
· Offers improved durability and wear life (up to 600% better than standard steels).
· Provides cleaner, more precise cuts with reduced friction.
· Suitable for high heat and high speed cutting environments.
· Compatible with Zund S3, G3 & L3 digital cutters using UCT and SCT tool heads.
Z101 Blade
· Tungsten carbide double-edged drag blade, asymmetric design with a step on one side 10 mm from the tip.
· Dimensions: Length 50 mm, width 8 mm, thickness 1.5 mm.
· Cutting angle of 60°.
· Max cutting depth of 6.8 mm.
· Designed for ridge-free inside cutting edge.
· Suitable for folding carton, hardfoam, magnetic foil, polycarbonate, polypropylene, PVC.
· Provides extremely precise and clean cuts.
Z102 and Z103 Blades
· Not explicitly detailed in the search results.
· Likely similar tungsten carbide oscillating blades compatible with Zund cutting machines.
· Typically used for various industrial cutting applications like the other Z-series blades.
· For precise specs, contacting suppliers or manufacturers is recommended.
Z83 Blade
· Tungsten carbide or hard metal (HM) oscillating drag blade.
· Dimensions: Thickness 1.5 mm, max cutting depth approx. 4.5-4.6 mm.
· Asymmetrical cutting edge with a centric tip.
· Pre-cut and post-cut both 0.84 x Tm.
· Designed to prevent displacement and raising of material during cutting.
· Ideal for printed materials, PVC, polycarbonate, polypropylene, folding carton, hardfoam, magnetic foil.
· Used in Zund cutters, known for clean cuts without splintering color on printed materials.
Summary Table
|
Blade |
Material |
Length (mm) |
Width (mm) |
Thickness (mm) |
Cutting Angle |
Max Cutting Depth (mm) |
Features / Applications |
|
Steel |
18" (~457) |
- |
- |
- |
- |
Lawn mower blade for EGO POWER+ Z6 mower |
|
|
Tungsten Carbide |
50 |
8 |
1.5 |
50° |
4.8 |
Double-edged, versatile, for canvas, cardboard, plastic |
|
|
Tungsten Carbide |
50 |
8 |
1.5 |
Similar to Z10 |
Similar to Z10 |
For Zund S3, G3, L3 cutters, precise cutting |
|
|
Z44 |
Tungsten Carbide |
50 |
8 |
1.5 |
60° |
14 |
Double-sided, for fibers, cardboard, leather, foam |
|
Z46 |
Tungsten Carbide |
50 |
7.8 |
1.5 |
45° |
20 |
High durability, precise, for tough materials |
|
Tungsten Carbide |
50 |
8 |
1.5 |
60° |
6.8 |
Asymmetric, ridge-free inside cut, for carton, PVC |
|
|
Z102 |
Tungsten Carbide? |
~50 |
~8 |
~1.5 |
- |
- |
Not detailed, likely similar to Z101/Z103 |
|
Tungsten Carbide? |
~50 |
~8 |
~1.5 |
- |
- |
Not detailed, likely similar to Z101/Z102 |
|
|
Z83 |
Tungsten Carbide/HM |
~50 |
~8 |
1.5 |
Asymmetrical |
~4.5 |
Asymmetrical, centric tip, ideal for printed materials |
Key Differences
· Material: Most Z-series blades are tungsten carbide for durability, except the Z6 which is steel for mower use.
· Cutting Angle: Varies from 45° (Z46) to 60° (Z44, Z101), affecting cut aggressiveness and material suitability.
· Cutting Depth: Ranges from about 4.5 mm (Z83) to 20 mm (Z46), indicating suitability for different material thicknesses.
· Design: Some blades are double-edged (Z10, Z44), some asymmetric for specialized cuts (Z101, Z83).
· Application: Z6 is for lawn mowers, others are industrial oscillating blades for digital cutters handling materials like cardboard, PVC, fabrics, foam, and composites.
