Model |
Blade Height / Length |
Thickness |
Max Cutting Depth |
Angle |
Material |
Blade Mount / Hole Size |
Applications |
Notes |
|
17.0 - 17.7 mm |
0.5 - 1.0 mm |
3.5 mm |
30° |
Tungsten Carbide |
Ø 3 mm hole |
Paper, Leather, Fabrics |
Precise cutting on thinner materials |
|
|
17.3 - 17.5 mm |
0.5 - 1.0 mm |
6.0 mm |
45° |
Tungsten Carbide |
Ø 2.7 - 3 mm hole |
Paper, Leather, Fabrics |
Deeper cutting capability than TL-051 |
|
|
17.7 - 18.0 mm |
0.5 mm |
6.0 mm |
45° |
Solid Tungsten Carbide |
Ø 2.7 mm hole |
Leather, Textile, Paper |
High wear resistance, double beve |
|
|
Not specified |
Not specified |
Not specified |
Not specified |
Tungsten Carbide |
Not specified |
Not specified |
Solid tungsten carbide |
|
|
Not specified |
Not specified |
Not specified |
Not specified |
Tungsten Carbide |
Not specified |
Not specified |
Solid tungsten carbide |
|
|
Not specified |
Not specified |
Not specified |
Not specified |
Tungsten Carbide |
Not specified |
Not specified |
Solid tungsten carbide |
Additional notes:
· The TL-051 is ideal for thinner materials requiring precise edge cutting with a maximum depth of 3.5 mm
· The TL-052 and TL-055 blades share similar dimensions and cutting depths (up to 6 mm) and are made from tungsten carbide for durability; TL-055 is often described as a solid tungsten carbide blade with double bevel grinding
· Blade thickness varies slightly between 0.5 mm and 1.0 mm depending on the model and source.
· Most blades have a cutting angle of 45°, except TL-051 which may also come in 30° versions.
· The blade mount hole diameter is typically around 2.7 to 3 mm.
· These blades are suitable for cutting materials like paper, leather, textiles, and fabrics commonly used in Gerber automated cutting machines such as Taurus, DCS, and Z1 models
· Detailed specifications for TL-056, TL-166, and TL-353 are limited in available sources, but they are recognized as part of the Gerber tangential blade family
