iEcho E56-2 Rotation Ceramics |
iEcho E57-2 Rotation Ceramics |
|
Blade Type Rotary / Circular
|
Blade Type Rotary / Circular |
|
Mounting 8mm Hole Diameter
|
Mounting 8mm Hole Diameter |
|
Blade Thickness 0.63 mm
|
Blade Thickness 0.63 mm (Standard for E57 series)
|
|
Max Cutting Depth 4.00 mm
|
Max Cutting Depth ~5.00 mm (Material dependent)
|
|
Key Materials Aramid, Carbon, Glass fibers
|
Key Materials Heavy textiles, Nylon, Polyester |
Key Blade Features
iEcho E56-2 Rotation Ceramics Knife Blade: Praised by users on platforms like Shenzhen Oyea for its ability to handle "fine detailing" and "tight curves" without damaging surrounding surfaces. It is frequently recommended for high-performance fibers such as Aramid and Carbon fiber due to its sharp, precision-ground edge.
iEcho E57-2 Rotation Ceramics Knife Blade: Often categorized alongside the E57 series for broader textile applications. It is designed to maintain a consistent edge during high-speed rotation (up to 11,000 rpm) in industrial environments. According to Shenzhen Oyea, these ceramic blades are finished ground with virgin materials to ensure a "smooth edge without burrs".
Material Compatibility
Both blades are primarily used with the iEcho DRT tool for flexible materials.
Textiles: Nylon fabric, Polyester fabric, and non-woven textiles.
Composites: Carbon fiber prepreg, Glass fibers, and Aramid fibers.
Specialty: Paper leather, flexible transparent PVC, and advertising light sheets.
Heat Resistance: Ceramic material is inherently more resistant to high temperatures than metal, making these blades ideal for heat-sensitive materials like PVC or thin acrylic where friction could cause melting.
Blade Life: While ceramic blades are brittle and can chip if they hit hard debris, they typically offer a significantly longer service life than steel when cutting soft materials, reducing the need for frequent replacements during large-scale production.
