Axyz Bt-57269 B1041l-20 KR1-20 Routers And Cutters Tungsten Carbide Knife Blades
AXYZ BT-57269 (part number B1041L-20 KR1-20) is a round-point solid tungsten carbide knife blade designed for high-frequency oscillating knife tools on AXYZ CNC routers and digital cutting systems. Enquire now
Share this:
 Facebook  Twitter  LinkedIn  Google+  Addthis
Axyz Bt-57269 B1041l-20 KR1-20 Routers And Cutters Tungsten Carbide Knife Blades



Axyz BT-57269(or B1041L-20) is industrial-grade high-frequency vibrating insert made of high-quality solid carbide (tungsten steel).As a core consumable, it is widely used in AXYZ CNC engraving and cutting machines (such as the Trident and Infinite series) equipped with vibrating toolheads, as well as various flatbed digital cutting equipment.

Technical Specifications
Property Specification
Part Numbers BT-57269 / B1041L-20
Tool Type Oscillating Knife Tool
Material Solid Tungsten Carbide
Tip Geometry Round Point
Max Cutting Depth 20 mm
Shank Diameter 6 mm
Overall Length 36 mm
Compatible Target Materials

  • Corrugated cardboard and folding boxboard

  • Coroplast (fluted plastic sheeting)

  • Soft foams, PE/EVA foam inserts, and insulation

  • Rubber and gasket materials

  • Heavy textiles, felt, and leather

Equivalent to: Summa 500-9834, Summa 500-0834, Multicam 84-00193-BT-57269 003612-MC140394 K8, AXYZ B1041L-20

Axyz Bt-57268 Bt-57268-30 Bt-57269 cnc Routers And Cutters Tungsten Carbide Knife Blades Specification Size Selection Comparison Table

The following are three core solid carbide (Tungsten Carbide) vibrating inserts commonly used in AXYZ CNC cutting machines and oscillating knife systems:BT-57268,BT-57268-30 as well as BT-57269 Specifications and Dimensions Selection and Parameter Comparison.

All three inserts belong to the B1041L series (Single Edge Round Point) and have a standard 6mm shank. Their main differences lie in the maximum depth of cut, the total length of the tool, and the corresponding cutting angle

Axyz Bt-57269 B1041l-20 Routers And Cutters Tungsten Carbide Knife Blades


Specifications and Size Selection and Comparison Table

Official model (AXYZ)

Industry standard code (OEM)

Shank diameter(Shank)

Maximum Cutting Depth

Overall blade length (OAL)

Blade angle

Cutting tool geometry

Cross-brand compatible codenames (MultiCam, etc.)

BT-57268

B1041L-25

6.00 mm

25.00 mm

46.00 mm

83.9°

Single-edged, rounded-point knife

84-00193-BT-57268
003612-MC7354 K10

BT-57268-30

B1041L-30

6.00 mm

30.00 mm

46.00 mm

84.0°

Single-edged, rounded-point knife

84-00193-BT-57268-30
Aristo 7394

BT-57269

B1041L-20

6.00 mm

20.00 mm

36.00 mm

82.3°

Single-edged, rounded-point knife

84-00193-BT-57269
003612-MC140394 K8
