Ronchini Rm-01039894 Cnc Digital Cutting Plotters Tungsten Carbide Replacement Blades

The Ronchini RM-01039894 is a tungsten carbide replacement knife blade designed for Ronchini Massimo automated digital cutting plotters and CNC flatbed cutting tables. Enquire now

Description

Ronchini Rm-01039894 Cnc Digital Cutting Plotters Tungsten Carbide Replacement Blades

The Ronchini RM-01039894 is a high-performance tungsten carbide knife blade designed for industrial automated cutting systems. It is versatile enough to be used as both a drag and an oscillating blade, primarily compatible with Ronchini Automated Cutting Machines and various other CNC cutting heads.

Edge: 0,00 mm
Angle: 25°
Thickness: 0,64 mm
Width: 5,60 mm
Length: 28,0 mm
Hardness: HV1600
Suitable to cut leather, cardboard, thin polyester. To make sharp edges.

Replacement for: XZ0017,BT-2317,Zund Z17 / 3910307,Esko T17, G42441220, 42441220, BLD-SF217, i-217,Bullmer B17,iEcho E17,Mecanumeric 100610390,COMPO008759,Blackman & White BW17,Comagrav FN12,Atom 01039894,Viliani 2157 T17,Ronchini RM-01039894

Common Material Applications
Because of its specialized geometry (smaller overcut with high edge control), the RM-01039894 blade performs best on thin-to-medium flexible substrates (up to 12 mm thickness):
Cardboard & Packaging: Corrugated cardboard, solid board, and folding cartons
Plastics & Foams: Corrugated plastic (Coroplast), thin foam boards, and gaskets
Textiles & Technical Media: Polyester fabrics, canvas, felt, and rubber sheet goods
Vinyls & Graphics: Self-adhesive vinyl, reflective media, and magnetic foils

Key Usage & Maintenance Recommendations
Oscillating Operation: For optimal cutting speeds and clean edge quality, operate this blade inside an oscillating toolhead (electric or pneumatic) rather than static drag cutting.
Handling Carbide: Tungsten carbide offers exceptional sharpness retention, but it is inherently brittle. Avoid lateral/prying forces on the blade tip, and ensure the cutting underlay felt or mat is free from debris.
Sourcing Alternatives: When ordering replacements, search for Ronchini RM-01039894, Zund Z17 / 3910307, or Atom 01039894 to find compatible multi-packs from industrial cutting tool suppliers
