Best Flatbed Cutter Blades For Summa F-Series Cutter F1612 F1625 F1432 F1832 F3220 F3232
The best flatbed cutter blades for the Summa F Series cutter F1612 F1625 F1432 F1832 F3220 F3232 depend on your specific cutting needs and materials, but here are the top recommended options:
1. 500-9801 Oscillating/Drag Knife Blade
· Replacement for Summa F Series (Part #500-9801)
· Suitable for thru cutting corrugate, foamboard, self-adhesive vinyl, polycarbonate, polyester, masking film, magnetic media, transfer paper, 3M VHB, folding carton, sandblasting mask, varnish blankets
· Cutting angle: Single edge 65°
· Max cutting depth: 12 mm (0.472 in)
· Made of fine grain tungsten carbide for durability
· Ideal for drag and oscillating cutting methods
2. Summa F Series Double Edge Cutout Knife (60°) - Part #500-9803
· Double edge blade with a 60° cutting angle
· Made of solid tungsten carbide for precision and minimal wear
· Max cutting depth: 6.5 mm
· Suitable for cutting paper (<200 gr), cardboard (300-500 gr), adhesive vinyl, PVC banner, expanded PVC board (≤ 2 mm), reflective sheeting, polypropylene sheets (≤ 1.2 mm), polycarbonate (≤ 0.6 mm), magnetic material
· Compatible with Summa F Series Tangential Module and Double Edge Cutout Tool
· Cuts on both knife sides for extended blade life
3. Other Summa F Series Blades
· Double edge blades with 50° cutting angle (Part #500-9802)
· V-Cut blades in hard metal (Part #500-9826)
· Various blades designed for specific cutting tasks and materials are available from Summa and authorized suppliers
Additional Notes
· Summa F Series cutters have a multifunctional head that can hold up to three modules simultaneously, allowing for versatile cutting techniques including drag, kiss-cutting, V-cutting, and routing
· For routing and thicker materials, Summa offers high-frequency router bits and tangential modules compatible with the F Series.
· It is recommended to use genuine Summa blades and consumables to ensure compatibility and optimal performance
In summary, for general cutting and versatility, the 500-9801 oscillating/drag knife and the 60° double edge cutout knife (#500-9803) are among the best blades for Summa F Series cutters F1612 F1625 F1432 F1832 F3220 F3232, covering a wide range of materials and cutting depths. For specialized applications, consider the other Summa blades designed for V-cutting or routin
