Esko Kongsberg Bld-Sf421 Flat Oscillating Knife Blades For Kongsberg Digital Cutting Machine G424582
The Esko Kongsberg BLD-SF421 is a high-precision, flat-shank oscillating knife blade designed for intricate detail work in digital cutting systems. It is characterized by its very fine, delicate profile, which allows for a minimal overcut when navigating complex geometries and small radii. This blad… Enquire now
Share this:
 Facebook  Twitter  LinkedIn  Google+  Addthis
Esko Kongsberg Bld-Sf421 Flat Oscillating Knife Blade For Kongsberg Digital Cutting Machine G42458257
Kongsberg Bld-Sf421 Blade,Kongsberg Bld-Sf421,Kongsberg Blade,Esko Bld-Sf421 Blade,Esko Bld-Sf421,Esko Blade,Bld-Sf421,Esko Kongsberg Knife Blade,Esko Kongsberg Blades,Esko Kongsberg Blade,Esko Blades,Kongsberg Blades
Recommended use
Corrugated stock, foam board and more. for oscillate knife with a 5'/25' cut angle, a single edge design.
CUTTER BRAND
Esko Kongsberg
ANGLE
63°/84°
KNIFE HEIGHT
28,00 mm
THICKNESS
0,63 mm
MAX. CUTTING DEPTH
17,20 mm
KNIFE TYPE
Flat, Oscillating blade, Pointed
REPLACEMENT
Yes
KNIFE/BLADE MOUNTING
flat 0,63 mm

Recommended Materials
This blade is optimized for a wide range of soft to semi-rigid materials, including:
  • Cardboard: Corrugated, solid, and honeycomb boards.
  • Foams: PE, PUR, and general foam boards.
  • Textiles & Leathers: Polyester fabrics, suede, and various hide leathers.
  • Specialty Media: Magnetic foil, rubber, felt, and PP corrugated plastic.

Tool Compatibility
The BLD-SF421 is designed to be used with specific tool heads and adapters depending on the machine series:
  • XL/XN/X/V Series: Compatible with the standard Oscillating Knife Tool and the MP HF knife tool (using adapter 34044107).
  • XE/C/XP Series: Fits the Hi-Force knife tool when used with adapter 34046557.

Replacement for:XZ0021 BT-2381 Colex T00421,Esko Kongsber G42458257 42458257 BLD-SF421,iEcho E21,Summa 500-0812 500-9812,Zund 3910314 Z21,Blackman & White BW21,Mécanuméric 100610370 COMPO008757,ATOM 01033569 01039907,Ronchini RM-01039907,Comagrav FNS13,Gerber MCT SE21 895022,MultiCam 94-02466-910.314
Kongsberg Bld-Sf421 Blade,Kongsberg Bld-Sf421,Kongsberg Blade,Esko Bld-Sf421 Blade,Esko Bld-Sf421,Esko Blade,Bld-Sf421,Esko Kongsberg Knife Blade,Esko Kongsberg Blades,Esko Kongsberg Blade,Esko Blades,Kongsberg Blades
If you have more questions to know ,please contact us .
Tel:+86-0769-88014625
Phone Number:+86-18823852826
Email:  info@china-oyea.com
            1659590865@qq.com
Web: www.china-oyea.com
We warmly welcome every customer to send us drawings for making customized product.  Contact with us ,you will get more than what you can !


Esko Kongsberg Bld-Sf421 Flat Oscillating Knife Blade, compatible with the Kongsberg Digital Cutting Machine (Model G4245825), is a high-quality product tailored for production, manufacturing, wholesale, and supply purposes. It stands out for its precision and reliability, catering to diverse industries with optimal performance.
