Axyz Bt1051l-7 Cnc Tangential Cutting Systems Tungsten Carbide Saber Knife Blades

AXYZ BT1051L-7 is a 60-degree, single-edged solid tungsten carbide saber knife blade designed for industrial CNC tangential cutting systems Enquire now

Description

Axyz Bt1051l-7 Cnc Tangential Cutting Systems Tungsten Carbide Saber Knife Blades

Axyz Knives,Axyz BT1051L-7,Axyz BT1051L-7 Knife,Axyz BT1051L-7 Blade,Axyz Knife,Axyz Blades

AXYZ BT1051L-7 is a Solid Micrograin Tungsten Carbide Saber Knife Blade engineered for precision drag and tangential cutting on AXYZ CNC digital finishing systems.

Technical Specifications & Geometry

Feature / Attribute	Value / Specification
Model / Series	BT1051L-7 (BT-Series Tangential Saber Blade)
Material Construction	Ultra-fine Micrograin Tungsten Carbide (VHM)
Blade Profile	Saber / Single-Edge Pointed Cutting Geometry
Shank Diameter	6.0 mm Cylindrical Shank
Max Cutting Depth	~7.0 mm (approx. 0.275 in)
Cutting Action	Tangential Drag / Passive Cutting

Unit & Tooling Compatibility

AXYZ Tool Heads: Compatible with the AXYZ Electric Tangential Knife Assembly (026054), Trident Tangential Knife Unit, and Saber Blade Cartridge (028755).
Compatible Machines: AXYZ Trident Series, AXYZ Infinite, Pacific, and Z-Series CNC Digital Finishing Tables equipped with knife-ready modules.

Recommended Substrates

Gasketing & Rubber: Nitrile, neoprene, silicone, and fibrous gasket materials.
Flooring & Heavy Plastics: Flexible PVC, semi-rigid vinyl flooring, and rubber tiles.
Cardboard & Packaging: Solid board, heavy folding cartons, and single/double-wall corrugated board.
Foams & Acoustic Media: High-density foam board, expanded foam, and acoustic felt panels.

Replacement for:Jwei J353 Esko Kongsberg G42443036 42443036 BLD-DF113 i-309 Summa 500-0803 500-9803 Colex T00313 Blackman & White BW113 MultiCam 94-02466-910.309-S Zund Z11 in 25 mm AXYZ BT1051L-7 Gerber MCT DE13 895013 Weni W353
