1. Material Composition and Structure:
- ACM panels consist of two thin aluminum sheets bonded to a non-aluminum core (usually polyethylene or a mineral-filled core), requiring bits that can handle both the aluminum surface and the softer core.
- Solid aluminum requires bits that can effectively cut through a homogenous metal without delamination.
2. Bit Geometry and Design:
- ACM router bits often feature shear cut geometry and helical cutter designs to reduce cutting force, minimize vibration, and prevent delamination or frayed edges during cutting of the composite layers.
- Aluminum router bits tend to be designed with geometries suited for clean metal cutting, often with carbide tips and single or multiple flutes optimized for chip evacuation and heat dissipation.
3. Cutting Performance Features:
- ACM bits focus on reducing tool wear and overheating, with chip evacuation channels adapted to the composite structure. They also often use coatings to reduce friction.
- Aluminum bits require higher durability and cooling mechanisms due to the metal's hardness and heat generation during cutting.
4. Application and Usage:
- Esko Kongsberg offers specialized router bits and tooling, including multiCUT-HP tool heads and milling spindles with liquid cooling systems to optimize cutting of ACM and aluminum.
- ACM bits are used for signage and architectural cladding materials such as Dibond and Alucobond, designed to deliver smooth cuts on delicate composite layers.
- Aluminum bits are optimized for solid metal machining, providing clean, precise edges with high-speed routing capabilities.
In summary, Esko Kongsberg ACM router bits are specially engineered for cutting layered aluminum composite panels with features that minimize delamination and wear, while aluminum router bits are robust tools optimized for machining solid aluminum metal, focusing on durability, cooling, and chip evacuation for efficient metal cutting.
|
Feature |
Esko Kongsberg Aluminum Router Bits |
|
|
Material Specialty |
Designed specifically for Aluminum Composite Material (ACM) such as Dibond, Alumicor, etc. |
Designed for cutting solid aluminum and aluminum alloys |
|
Coating/Surface |
Often coated with NeoGuard™ or similar coatings for longer bit life and reduced wear |
May have specialized coatings for heat and wear resistance, optimized for metals |
|
Flute Design |
Single or up-cut single flute to optimize chip evacuation and avoid delamination |
Usually multi-flute or spiral design to control chip removal and reduce vibration |
|
Diameter Options |
Common sizes from 2mm to 6mm |
Variable, depending on the application, often slightly larger diameters for aluminum |
|
Recommended Use |
Routing, engraving, and cutting of layered ACM panels |
Routing and milling solid aluminum or aluminum plates |
|
Cooling/Lubrication |
LubriCool system compatibility for cooling during cutting of ACM |
Similar options for cooling available due to heat sensitivity of aluminum |
|
Performance Focus |
Minimizing chip clogging, frayed edges, and core melting |
Prevent tool wear, maintain edge smoothness, reduce vibration |
|
Compatible Machines |
As above, plus machines geared for metal routing |
|
|
Tool Life & Durability |
Coatings extend life by up to 2.5x in ACM routing jobs |
High durability but typically more wear due to tougher metal cutting |
Esko Kongsberg ACM and Aluminum Router Bits are produced and supplied for various applications, including OEM and ODM needs, with a focus on quality and compatibility. Shenzhen Oyea Machinery Co., Ltd. specializes in manufacturing, wholesale production, and global distribution of these tools at competitive prices.
